The Afterburner Sport is the flagship 5-inch performance drone from 2RAW, designed to push the boundaries of speed, agility, and durability. Building on the original Afterburner concept, the Sport model introduces key enhancements that elevate its performance to new heights, making it the ideal choice for those seeking the ultimate high-speed, high-performance drone – perfect for chase and race applications.

Aeroshell Design

Optimized to protect internal components while minimizing drag for maximum aerodynamic efficiency.

Top-Mounted Action Camera

Supports a 10-60° field of view with no propeller visibility, ensuring a pristine 16:9 aspect ratio for clean, uninterrupted footage during high speed chase sequences.

Bottom-Mounted Battery

Strategically placed for optimal center of gravity and balanced flight dynamics, ensuring exceptional stability and control.

Compact 5-inch Footprint: Designed for unmatched agility and responsiveness, allowing for precision maneuvers in high-speed environments.

CNC Machined Parts

Crafted for maximum durability and ease of repair, providing quick access to internal components while enhancing structural integrity.

Product Name：Afterburner Sport O4 Frame Kit

Wheelbase: 210mm

Frame Dimension: L48*W148*H77 mm

Arm Thickness: 3mm

Bottom Plate Thickness: 3mm

Top Plate Thickness: 3mm

Max Flight Stack Height: 17.5mm

Max VTX Height: 17mm

Flight Stack Mounting: 30*30/Φ3mm

VTX Mounting: 25.5*25.5/Φ2mm 20*20/Φ2mm

Motor Mounting: 16*16/Φ3mm

Weight: 316g±5g

Compatibility: DJI O4 Air Unit Pro

1 x Afterburner Sport Frame Kit

1 x TPU Parts

4 x Motor Wire Shield Tube

2 x Battery Anti-Slip Pad

2 x Battery Strap

1 x Screw Bag

Due to manufacturing processes, the thickness of our products may have a standard manufacturing tolerance of ±0.2mm. The size of the hole may have a standard manufacturing tolerance of ±0.1mm.
